For the repair and manufacture of buckets and shovels, we offer rolled hardened profiles cut to length as required by the customer, with a bevel of hardness 230 HB, 400 HB, 500 HB in various thicknesses. The advantage of this wear-resistant material is long service life (the rolled tough edge is not affected by burning), good weldability and, for selected items, the possibility of immediate delivery. Its application is very broad, from construction machinery such as mini excavators, backhoe loaders, excavators, skid-steer or wheel loaders, bulldozers, through road maintenance for snow ploughs, to machines used in agriculture and forestry.
| CUTTING EDGES WITH SINGLE-SIDED BEVEL, HARDNESS 500 HB | ||||||||
|---|---|---|---|---|---|---|---|---|
| Designation | Dimensions (mm) | Profile Length max. in mm (L) |
Weight (kg/m) |
|||||
| A | B | C | D | E | ||||
| PM08012BJ500 | 80 | 12 | 20,2 ° | 5 | 6300 | 7,1 | ||
| PM11012BJ500 | 110 | 12 | 23,9 ° | R3 | 3 | 6000 | 9,7 | |
| PM11016BJ500 | 110 | 16 | 23,9 ° | R3 | 7 | 6000 | 13,1 | |
| PM15016BJ500 | 150 | 16 | 24 ° | 5 | 7 | 6000 | 18 | |
| PM15020BJ500 | 150 | 20 | 22,6 ° | 5 | 5 | 6000 | 21,5 | |
| PM20020BJ500 | 200 | 20 | 23 ° | 8 | 6 | 6000 | 29,5 | |
| PM20025BJ500 | 200 | 25 | 23 ° | 8 | 11 | 6000 | 37,4 | |
| PM24525BJ500 | 245 | 25 | 22,6 ° | 10 | 8 | 6000 | 44,9 | |
| PM25025BJ500 | 250 | 25 | 22,6 ° | 10 | 6 | 6000 | 45,6 | |
| PM25030BJ500 | 250 | 30 | 22,6 ° | 10 | 11 | 6000 | 55,3 | |
| PM27032BJ500 | 270 | 32 | 23 ° | 10 | 10 | 6000 | 63,1 | |
| PM27035BJ500 | 270 | 35 | 23 ° | 10 | 13 | 6000 | 69,1 | |
| PM30030BJ500 | 300 | 30 | 23 ° | 10 | 8 | 6100 | 66,1 | |
| PM30035BJ500 | 300 | 35 | 23 ° | 10 | 13 | 6100 | 77,7 | |
| PM30040BJ500 | 300 | 40 | 23 ° | 10 | 18 | 6100 | 89,4 | |
| PM30050BJ500 | 300 | 50 | 23 ° | 10 | 28 | 6100 | 112,9 | |
| PM40040BJ500 | 400 | 40 | 24 ° | 12 | 15 | 6100 | 119,5 | |
| PM40045BJ500 | 400 | 45 | 24 ° | 12 | 20 | 6100 | 135,2 | |
| PM40050BJ500 | 400 | 50 | 24 ° | 12 | 25 | 6100 | 150,9 | |
| CUTTING EDGES WITH SINGLE-SIDED BEVEL, HARDNESS 400 HB | ||||||||
|---|---|---|---|---|---|---|---|---|
| Designation | Dimensions (mm) | Profile Length max. in mm (L) |
Weight (kg/m) |
|||||
| A | B | C | D | E | ||||
| PM08012BJ400 | 80 | 12 | 20,2 ° | 5 | 6300 | 7,1 | ||
| PM11012BJ400 | 110 | 12 | 23,9 ° | R3 | 3 | 6000 | 9,7 | |
| PM11016BJ400 | 110 | 16 | 23,9 ° | R3 | 7 | 6000 | 13,1 | |
| PM15016BJ400 | 150 | 16 | 24 ° | 5 | 7 | 6000 | 18 | |
| PM15020BJ400 | 150 | 20 | 22,6 ° | 5 | 5 | 6000 | 21,5 | |
| PM20020BJ400 | 200 | 20 | 23 ° | 8 | 6 | 6000 | 29,5 | |
| PM20025BJ400 | 200 | 25 | 23 ° | 8 | 11 | 6000 | 37,4 | |
| PM24525BJ400 | 245 | 25 | 22,6 ° | 10 | 8 | 6000 | 44,9 | |
| PM25025BJ400 | 250 | 25 | 22,6 ° | 10 | 6 | 6000 | 45,6 | |
| PM25030BJ400 | 250 | 30 | 22,6 ° | 10 | 11 | 6000 | 55,3 | |
| PM27032BJ400 | 270 | 32 | 23 ° | 10 | 10 | 6000 | 63,1 | |
| PM27035BJ400 | 270 | 35 | 23 ° | 10 | 13 | 6000 | 69,1 | |
| PM30030BJ400 | 300 | 30 | 23 ° | 10 | 8 | 6100 | 66,1 | |
| PM30035BJ400 | 300 | 35 | 23 ° | 10 | 13 | 6100 | 77,7 | |
| PM30040BJ400 | 300 | 40 | 23 ° | 10 | 18 | 6100 | 89,4 | |
| PM30050BJ400 | 300 | 50 | 23 ° | 10 | 28 | 6100 | 112,9 | |
| PM40040BJ400 | 400 | 40 | 24 ° | 12 | 15 | 6100 | 119,5 | |
| PM40045BJ400 | 400 | 45 | 24 ° | 12 | 20 | 6100 | 135,2 | |
| PM40050BJ400 | 400 | 50 | 24 ° | 12 | 25 | 6100 | 150,9 | |
| CUTTING EDGES WITH SINGLE-SIDED BEVEL, HARDNESS 250 HB | ||||||||
|---|---|---|---|---|---|---|---|---|
| Designation | Dimensions (mm) | Profile Length max. in mm (L) |
Weight (kg/m) |
|||||
| A | B | C | D | E | ||||
| PM08012BJ250 | 80 | 12 | 20,2 ° | 5 | 6300 | 7,1 | ||
| PM11012BJ250 | 110 | 12 | 23,9 ° | R3 | 3 | 6000 | 9,7 | |
| PM11016BJ250 | 110 | 16 | 23,9 ° | R3 | 7 | 6000 | 13,1 | |
| PM15016BJ250 | 150 | 16 | 24 ° | 5 | 7 | 6000 | 18 | |
| PM15020BJ250 | 150 | 20 | 22,6 ° | 5 | 5 | 6000 | 21,5 | |
| PM20020BJ250 | 200 | 20 | 23 ° | 8 | 6 | 6000 | 29,5 | |
| PM20025BJ250 | 200 | 25 | 23 ° | 8 | 11 | 6000 | 37,4 | |
| PM24525BJ250 | 245 | 25 | 22,6 ° | 10 | 8 | 6000 | 44,9 | |
| PM25025BJ250 | 250 | 25 | 22,6 ° | 10 | 6 | 6000 | 45,6 | |
| PM25030BJ250 | 250 | 30 | 22,6 ° | 10 | 11 | 6000 | 55,3 | |
| PM27032BJ250 | 270 | 32 | 23 ° | 10 | 10 | 6000 | 63,1 | |
| PM27035BJ250 | 270 | 35 | 23 ° | 10 | 13 | 6000 | 69,1 | |
| PM30030BJ250 | 300 | 30 | 23 ° | 10 | 8 | 6100 | 66,1 | |
| PM30035BJ250 | 300 | 35 | 23 ° | 10 | 13 | 6100 | 77,7 | |
| PM30040BJ250 | 300 | 40 | 23 ° | 10 | 18 | 6100 | 89,4 | |
| PM30050BJ250 | 300 | 50 | 23 ° | 10 | 28 | 6100 | 112,9 | |
| PM40040BJ250 | 400 | 40 | 24 ° | 12 | 15 | 6100 | 119,5 | |
| PM40045BJ250 | 400 | 45 | 24 ° | 12 | 20 | 6100 | 135,2 | |
| PM40050BJ250 | 400 | 50 | 24 ° | 12 | 25 | 6100 | 150,9 | |
| CUTTING EDGES WITH DOUBLE-SIDED BEVEL, HARDNESS 500 HB | |||||||
|---|---|---|---|---|---|---|---|
| Designation | Dimensions (mm) | Profile Length max. in mm (L) |
Weight (kg/m) |
||||
| A | B | C | D | ||||
| PM12015BD500 | 120 | 15 | 25 ° | 5 | 6500 | 12,2 | |
| PM15216BD500 | 152,4 | 15,9 | 25 ° | 5 | 6500 | 17,4 | |
| PM15219BD500 | 152,4 | 19,1 | 25 ° | 8,1 | 6500 | 21,0 | |
| PM20316BD500 | 203,2 | 15,9 | 25 ° | 5 | 6500 | 23,7 | |
| PM20319BD500 | 203,2 | 19,1 | 25 ° | 8,1 | 6500 | 28,5 | |
| PM20325BD500 | 203,2 | 25,4 | 25 ° | 14,4 | 6500 | 38,5 | |
| PM25419BD500 | 254 | 19,1 | 25 ° | 7,1 | 6500 | 36,0 | |
| PM25425BD500 | 254 | 25,4 | 25 ° | 13,4 | 6500 | 48,5 | |
| PM25430BD500 | 254 | 30 | 25 ° | 18 | 6500 | 57,7 | |
| PM25432BD500 | 254 | 32 | 25 ° | 20 | 6500 | 61,4 | |
| PM25435BD500 | 254 | 35 | 25 ° | 23 | 6500 | 67,4 | |
| PM25441BD500 | 254 | 41 | 25 ° | 29 | 6500 | 79,3 | |
| PM28025BD500 | 280 | 25 | 22,5 ° | 7 | 6500 | 48,9 | |
| PM30525BD500 | 304,8 | 25,4 | 22,5 ° | 9,5 | 6500 | 56,0 | |
| PM30529BD500 | 304,8 | 28,5 | 22,5 ° | 12,6 | 6500 | 63,6 | |
| PM30532BD500 | 304,8 | 32 | 22,5 ° | 16,1 | 6500 | 71,8 | |
| PM33025BD500 | 330 | 25 | 22,5 ° | 11 | 6500 | 61,0 | |
| PM33029BD500 | 330 | 28,5 | 22,5 ° | 14,5 | 6500 | 70,1 | |
| PM33030BD500 | 330 | 30 | 22,5 ° | 16 | 6500 | 74,0 | |
| PM33032BD500 | 330 | 32 | 22,5 ° | 18 | 6500 | 79,2 | |
| PM33035BD500 | 330 | 35 | 22,5 ° | 21 | 6500 | 87,0 | |
| PM33038BD500 | 330 | 38 | 22,5 ° | 24 | 6500 | 94,7 | |
| PM33041BD500 | 330 | 41 | 22,5 ° | 27 | 6500 | 102,5 | |
| PM33050BD500 | 330 | 50 | 22,5 ° | 36 | 6500 | 126,1 | |
| PM36030BD500 | 360 | 30 | 22,5 ° | 8 | 6500 | 75,6 | |
| PM36035BD500 | 360 | 35 | 22,5 ° | 13 | 6500 | 89,9 | |
| PM36040BD500 | 360 | 40 | 22,5 ° | 18 | 6500 | 103,9 | |
| PM40625BD500 | 406 | 25 | 22,5 ° | 9 | 6500 | 74,8 | |
| PM40629BD500 | 406 | 28,5 | 22,5 ° | 12,5 | 6500 | 86,0 | |
| PM40632BD500 | 406 | 32 | 22,5 ° | 16 | 6500 | 97,1 | |
| PM40635BD500 | 406 | 35 | 22,5 ° | 19 | 6500 | 106,7 | |
| PM40638BD500 | 406 | 38 | 22,5 ° | 22 | 6500 | 116,0 | |
| PM40641BD500 | 406 | 41 | 22,5 ° | 25 | 6500 | 125,8 | |
| PM40645BD500 | 406 | 45 | 22,5 ° | 29 | 6500 | 138,6 | |
| PM40650BD500 | 406 | 50 | 22,5 ° | 34 | 6500 | 154,5 | |
| PM40660BD500 | 406 | 60 | 22,5 ° | 44 | 6500 | 186,2 | |
| DRILLED DOUBLE-SIDED BEVELLED CUTTING EDGES, HARDNESS 500 HB |
||||||||
|---|---|---|---|---|---|---|---|---|
| Designation | Dimensions (mm) | Profile Length max. in mm (L) |
Weight (kg/m) |
|||||
| A | B | D | E | F | G | |||
| PM15216BD500V658 | 152 | 6" | 16 | 5/8" | 5 | 25 ° | 16 | 5/8" | 152,4 | 6" | 6500 | 17,4 |
| PM15219BD500V658 | 152 | 6" | 19 | 3/4" | 8 | 25 ° | 16 | 5/8" | 152,4 | 6" | 6500 | 20,1 |
| PM20319BD500V458 | 203 | 8" | 19 | 3/4" | 8 | 25 ° | 16 | 5/8" | 101,6 | 4" | 5000 | 28,5 |
| PM20319BD500V658 | 203 | 8" | 19 | 3/4" | 8 | 25 ° | 16 | 5/8" | 152,4 | 6" | 6500 | 28,5 |
| PM20319BD500V634 | 203 | 8" | 19 | 3/4" | 8 | 25 ° | 20 | 3/4" | 152,4 | 6" | 6500 | 28,4 |
| PM20325BD500V634 | 203 | 8" | 25 | 1" | 14 | 25 ° | 20 | 3/4" | 152,4 | 6" | 6500 | 38,5 |
| PM25425BD500V634 | 254 | 10" | 25 | 1" | 12 | 25 ° | 20 | 3/4" | 152,4 | 6" | 6500 | 48,6 |
| PM25425BD500V678 | 254 | 10" | 25 | 1" | 12 | 25 ° | 22 | 7/8" | 152,4 | 6" | 6500 | 48,5 |
| PM25425BD500V61 | 254 | 10" | 25 | 1" | 12 | 25 ° | 25 | 1" | 152,4 | 6" | 6500 | 48,4 |
| PM25438BD500V61 | 254 | 10" | 38 | 1 1/2" | 25 | 25 ° | 25 | 1" | 152,4 | 6" | 6500 | 73 |
| PM33029BD500V61 | 330 | 13" | 28,5 | 1 1/8" | 15 | 22,3 ° | 25 | 1" | 152,4 | 6" | 6500 | 70,2 |
| PM33029BD500V6114 | 330 | 13" | 28,5 | 1 1/8" | 15 | 22,3 ° | 32 | 1 1/4" | 152,4 | 6" | 6500 | 70,1 |
| PM33032BD500V61 | 330 | 13" | 32 | 1 1/4" | 21,5 | 22,3 ° | 25 | 1" | 152,4 | 6" | 6500 | 79,5 |
| PM33035BD500V678 | 330 | 13" | 35 | 1 1/2" | 21,5 | 22,3 ° | 22 | 7/8" | 152,4 | 6" | 6500 | 86,9 |
| PM33035BD500V61 | 330 | 13" | 35 | 1 1/2" | 21,5 | 22,3 ° | 25 | 1" | 152,4 | 6" | 6500 | 86,8 |
| PM33041BD500V61 | 330 | 13" | 41 | 1 5/8" | 27,5 | 22,3 ° | 25 | 1" | 152,4 | 6" | 6500 | 102,5 |
| PM40641BD500V61 | 406 | 16" | 41 | 1 5/8" | 24,5 | 22,3 ° | 25 | 1" | 152,4 | 6" | 6500 | 125,8 |
| PM40641BD500V6114 | 406 | 16" | 41 | 1 5/8" | 24,5 | 22,3 ° | 32 | 1 1/4" | 152,4 | 6" | 6500 | 125,6 |
| PM40650BD500V61 | 406 | 16" | 50 | 2" | 27,5 | 22,3 ° | 25 | 1" | 152,4 | 6" | 6500 | 154,5 |
| DOUBLE-SIDED CURVED CUTTING EDGES, HARDNESS 500 HB |
|||||||
|---|---|---|---|---|---|---|---|
| Designation | Dimensions (mm) | Profile Length max. in mm (L) |
Weight (kg/m) |
||||
| A | B | C | D | R | |||
| PM15213DP500 | 152,4 | 12,7 | 2,5 | 33,3 | 273 | 6500 | 13,3 |
| PM15216DP500 | 152,4 | 15,9 | 5,5 | 33,3 | 273 | 6500 | 17,2 |
| PM15219DP500 | 152,4 | 19,1 | 8,6 | 33,3 | 273 | 6500 | 20,4 |
| PM20316DP500 | 203,2 | 15,9 | 5,5 | 33,3 | 273 | 6500 | 23,3 |
| PM20319DP500 | 203,2 | 19,1 | 8,6 | 33,3 | 273 | 6500 | 28,3 |
| PM20325DP500 | 203,2 | 25,4 | 14,7 | 33,3 | 273 | 6500 | 38,7 |
| SPECIAL ADD-ON CUTTING EDGES, HARDNESS 500 HB | |||||||
|---|---|---|---|---|---|---|---|
| Designation | Dimensions (mm) | Profile Length max. in mm (L) |
Weight (kg/m) |
||||
| A | B | C | D | E | |||
| PM10111BP500 | 101 | 11 | 21 | 46 | 3 | 6100 | 9,8 |
| PM15116BP500 | 151 | 16 | 32 | 68 | 6 | 6100 | 21,3 |
| PM20319BP500 | 203 | 19 | 32 | 127 | 5 | 6100 | 31,0 |
| PM25429BP500 | 254 | 29 | 58 | 130 | 10 | 7400 | 66,2 |
| PM25440BP500 | 254 | 40 | 69 | 130 | 21 | 7400 | 88,5 |
| ARMOUR PLATING - PROFILES WITHOUT BEVEL, HARDNESS 500 HB |
||||
|---|---|---|---|---|
| Designation | Dimensions (mm) | Profile Length max. in mm (L) |
Weight (kg/m) |
|
| A | B | |||
| PM06008PP500 | 60 | 8 | 6000 | 3,8 |
| PM06010PP500 | 60 | 10 | 6000 | 4,7 |
| PM08010PP500 | 80 | 10 | 6000 | 6,3 |
| PM08015PP500 | 80 | 15 | 6000 | 9,4 |
| PM10010PP500 | 100 | 10 | 6000 | 7,8 |
| PM10012PP500 | 100 | 12 | 6000 | 9,3 |
| PM10015PP500 | 100 | 15 | 6000 | 11,7 |
| PM10020PP500 | 100 | 20 | 6000 | 16,0 |
| PM12012PP500 | 120 | 12 | 6000 | 11,2 |
| PM12015PP500 | 120 | 15 | 6000 | 14,1 |
| PM12020PP500 | 120 | 20 | 6000 | 18,7 |
| PM13015PP500 | 130 | 15 | 6000 | 15,2 |
| PM15015PP500 | 150 | 15 | 6000 | 17,6 |
| PM15020PP500 | 150 | 20 | 6000 | 23,4 |
| PM16015PP500 | 160 | 15 | 6000 | 18,7 |
| PM18020PP500 | 180 | 20 | 6000 | 28,1 |
| PM20015PP500 | 200 | 15 | 6000 | 23,4 |
| PM20020PP500 | 200 | 20 | 6000 | 31,2 |
| PROFILES FOR TRACK PAD RENOVATION, HARDNESS 500 HB | ||||||
|---|---|---|---|---|---|---|
| Designation | Dimensions (mm) | Profile Length max. in mm (L) |
Weight (kg/m) |
|||
| A | B | B1 | B2 | |||
| PM03016RD500 | 30 | 16 | 4 | 5 | 3000 | 2,8 |
| PM04022RD500 | 40 | 22 | 5 | 7 | 3000 | 5,2 |
| PM05027RD500 | 50 | 27 | 6 | 10 | 3000 | 8,4 |
| PM06530RD500 | 65 | 30 | 10 | 10 | 3000 | 12,0 |
| PM06837RD500 | 68 | 37 | 12 | 14 | 3000 | 15,7 |
* Hardness 250 HB and 400 HB on request
** Other dimensions on request
| HARDENED ROUND BAR, HARDNESS 400 HB |
|||||
|---|---|---|---|---|---|
| Designation | Dimensions (mm) | Profile Length max. in mm (L) |
Weight (kg/m) |
||
| Diameter (D) |
Tolerance | ||||
| PM00020TK400 | 20 | +/- 0,5 | 5000 | 2,47 | |
| PM00022TK400 | 22 | +/- 0,5 | 5000 | 2,98 | |
| PM00024TK400 | 24 | +/- 0,5 | 5000 | 3,55 | |
| PM00025TK400 | 25 | +/- 0,5 | 5000 | 3,85 | |
| PM00026TK400 | 26 | +/- 0,6 | 5000 | 4,17 | |
| PM00027TK400 | 27 | +/- 0,6 | 5000 | 4,49 | |
| PM00028TK400 | 28 | +/- 0,6 | 5000 | 4,83 | |
| PM00030TK400 | 30 | +/- 0,6 | 5000 | 5,55 | |
| PM00032TK400 | 32 | +/- 0,6 | 5000 | 6,31 | |
| PM00035TK400 | 35 | +/- 0,6 | 5000 | 7,55 | |
| PM00036TK400 | 36 | +/- 0,8 | 5000 | 7,99 | |
| PM00038TK400 | 38 | +/- 0,8 | 5000 | 8,9 | |
| PM00040TK400 | 40 | +/- 0,8 | 5000 | 9,86 | |
| PM00042TK400 | 42 | +/- 0,8 | 5000 | 10,88 | |
| PM00045TK400 | 45 | +/- 0,8 | 5000 | 12,48 | |
| PM00048TK400 | 48 | +/- 0,8 | 5000 | 14,2 | |
| PM00050TK400 | 50 | +/- 0,8 | 5000 | 15,41 | |
| PM00052TK400 | 52 | +/- 1,0 | 5000 | 16,67 | |
| PM00055TK400 | 55 | +/- 1,0 | 5000 | 18,65 | |
| PM00060TK400 | 60 | +/- 1,0 | 5000 | 22,19 | |
| PM00063TK400 | 63 | +/- 1,0 | 5000 | 14,47 | |
| PM00065TK400 | 65 | +/- 1,0 | 5000 | 26,05 | |
| PM00070TK400 | 70 | +/- 1,0 | 5000 | 30,21 | |
| PM00073TK400 | 73 | +/- 1,0 | 5000 | 32,85 | |
| PM00075TK400 | 75 | +/- 1,0 | 5000 | 34,68 | |
| PM00080TK400 | 80 | +/- 1,0 | 5000 | 39,46 | |
| PM00085TK400 | 85 | +/- 1,3 | 5000 | 44,54 | |
| PM00090TK400 | 90 | +/- 1,3 | 5000 | 49,94 | |
| PM00095TK400 | 95 | +/- 1,3 | 5000 | 55,64 | |
| PM00100TK400 | 100 | +/- 1,3 | 5000 | 61,65 | |
* Other dimensions and precision designs with smaller tolerance on request.
Hardness (HBW) 370–430 HB; hardness 500 HB on request; rolled surface; typical tensile strength (MPa) 1000; minimum notch toughness (J) 30; good weldability.
On request, we are also prepared to manufacture cutting edges of atypical dimensions.
